PART NO.
THREAD TUBE O.D. DIMENSIONS E F L S P1CM-12-10 M12X1.5 M10X1 6 23.5 14 P1CM-14-12 M14X1.5 M12X1.5 8 29 17 P1CM-14-18 M14X1.5 M18X1.5 8 30.5 24 P1CM-16-14 M16X1.5 M14X1.5 10 30 19 P1CM-16 M16X1.5 M16X1.5 10 31 22 P1CM-16-18 M16X1.5 M18X1.5 10 31.5 24 P1CM-16-22 M16X1.5 M22X1.5 10 35 27 P1CM-18-14 M18X1.5 M14X1.5 12 30 19 P1CM-18-16 M18X1.5 M16X1.5 12 31 22 P1CM-18 M18X1.5 M18X1.5 12 31.5 24 P1CM-18-22 M18X1.5 M22X1.5 12 35 27 P1CM-22-16 M22X1.5 M16X1.5 15 32 24 P1CM-22-18 M22X1.5 M18X1.5 15 32.5 24 P1CM-22 M22X1.5 M22X1.5 15 36 27 P1CM-26-18 M26X1.5 M18X1.5 18 33.5 27 P1CM-26-22 M26X1.5 M22X1.5 18 34 27 P1CM-30-22 M30X2 M22X1.5 22 38 32 P1CM-30-26 M30X2 M26X1.5 22 40 32 P1CM-30-27 M30X2 M27X1.5 22 42 32 P1CM-36-33 M36X2 M33X2 28 41 41 P1CM-45-42 M45X2 M42X2 35 48 50 P1CM-52-48 M52X2 M52X2 42 52 55
Pehel | P1CM | Hydraulic Metric Male 60° Seat Sealing or Bonded Seal Stud Ends Adapters
PEHEL Hydraulic Model: P1CM
QTY:
Material: Carbon steel
Brand: Pehel
Color: Silver
Thread: Metric
Connector: male adapter
Size: 1/4"-2"
About the item:
1. Precision adapter – designed for metric hydraulic connections.
2. Metric thread standard – conforms to DIN/ISO for exact fit and compatibility.
3. Metric 60deg cone sealing – ensures reliable metal-to-metal leak-proof connections.
4. Durable steel body – corrosion-resistant for high-pressure durability.
5. Versatile application – ideal for metric port systems requiring 60° cone sealing.
