PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH C S2 s2 Per hundred weight Weight per case 28611-14-04 M14X1.5 6 4 10.5 19 19 5.1 250 28611-14-06 M14X1.5 10 6 10.5 19 19 6 170 28611-16-04 M16X1.5 6 4 10 22 22 7.2 150 28611-16-05 M16X1.5 8 5 9.3 22 22 6.7 150 28611-16-06 M16X1.5 10 6 10 22 22 7.5 150 28611-18-04 M18X1.5 6 4 11.5 24 24 8.7 150 28611-18-06 M18X1.5 10 6 11.5 24 24 9.3 120 28611-18-05 M18X1.5 8 5 11.5 24 24 9.2 120 28611-20-08 M22X1.5 12 8 12 27 27 12.2 100 28611-22-08 M22X1.5 12 8 14 27 27 11.9 100 28611-24-08 M24X1.5 12 8 15 32 32 17.4 80 28611-24-10 M24X1.5 16 10 15.1 32 32 17.7 130 28611-30-12 M30X1.5 20 12 18.3 36 36 24.9 70 28611-33-12 M33X1.5 20 12 21.3 41 41 32.2 50 28611-33-16 M33X1.5 25 16 21.3 41 41 37.8 50 28611-36-20 M36X1.5 32 20 20 46 46 56.6 30 28611-42-24 M42X1.5 40 24 18.8 55 55 90.1 28
PEHEL | JIS Metric Female 60° Cone Seat Fitting, Hydraulic Threaded Fitting
PEHEL Hydraulic Model: 28611
QTY:
28611 Japanese Metric Male Straight Fittings, 60° Cone Seat
Type: JIS Metric Female 60° Cone Seat Fitting
Thread: Metric Female
Sealing: 60° Cone Seat
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc-plated
1.JIS metric female 60° cone seat fitting, designed for hydraulic threaded connections with a 60° cone sealing surface.
2.Female metric threads allow secure engagement with corresponding male threaded components.
3.The 60° cone seat provides metal-to-metal sealing through line contact when mated with a matching cone.
4.Manufactured from high-strength carbon steel with anti-rust surface treatment.
5.Precision machined threads and cone surface ensure consistent fit and reliable sealing.
