light tube clamp: Structure: assembly including cover plate, rail nut, clamp body,hexagon bolts
.jpg)
.jpg)
.jpg)
.jpg)
Clamp size Twin welding plate Multiple weldv plate Mounting rail Rail nut Order code Size Order code Size Order code Size Order code Size d a e d a e h a b c 0 PTL-C0 - 30 61 PTL-D0
(9 Twin )- 30 298 PTL-E1
PTL-E2
PTL-E3
11
14
30
PTL-F 25.4 10.4 12 1 PTL-C1 20 35 69 PTL-D1
(9Twin)20 35 349 2 PTL-C2 26 43 86 PTL-D2
(9Twin )26 43 427 3 PTL-C3 33 52 104 PTL-D3
(9Twin)33 52 516 4 PTL-C4 40 60 117 PTL-D4
(4Twin )40 60 297 5 PTL-C5 52 75 145 PTL-D5
(4Twin )52 75 370 6 PTL-C6 66 90 176 PTL-D6
(4Twin )66 90 446
Pehel | Light Tube Clamp DIN 3015 Assembly With Cover Plate, Rail Nut, Clamp Body & Hexagon Bolts
PEHEL Hydraulic Model: PTL-C, PTL-E
QTY:
- light tube clamp: Structure: assembly including cover plate, rail nut, clamp body,hexagon bolts
- Connector Type: DIN3015 light tube clamp assembly
- Standard: DIN 3015 Light type
- Structure / Property: Assembly including cover plate, rail nut, clamp body, hexagon bolts
About the item:
- 1.DIN 3015 Light Tube Clamp is a complete assembly including cover plate, rail nut, clamp body and hexagon bolts
- 2.Standard DIN3015 light series specification, pre-assembled kit for fast hydraulic tube installation
- 3.Solid clamp body firmly secures hydraulic tubes, reduces vibration and prevents pipeline abrasion
- 4.Matching cover plate protects tube outer surface; rail nut supports sliding adjustment on mounting rail
- 5.High-strength hexagon bolts deliver stable clamping force for long-term light-load pipe fixing
- 6.Pehel brand & OEM service supported, DIN 3015 light tube clamp assemblies for industrial hydraulic pipelines
