THREAD DIMENSIONS PART NO. E F A B S1 S2 2J4-04 7/16"X20 7/16"X20 21.5 9.5 11 17 2J4-05 1/2"X20 1/2"X20 22 9 14 19 2J4-06 9/16"X18 9/16"X18 22.8 9.5 14 19 2J4-08 3/4"X16 3/4"X16 26.8 10.8 19 24 2J4-10 7/8"X14 7/8"X14 31 12 22 27 2J4-12 1.1/16"X12 1.1/16"X12 35.5 13 27 32 2J4-14 1.3/16"X12 1.3/16"X12 37 15 30 36 2J4-16 1.5/16"X12 1.5/16"X12 38.5 14 33 41 2J4-20 1.5/8"X12 1.5/8"X12 43 15 41 50 2J4-24 1.7/8"X12 1.7/8"X12 49 19 48 55 2J4-32 2.1/2"X12 2.1/2"X12 56 23.5 63 75
PEHEL/45° ELBOW JIC MALE 74° CONE /JIC FEMALE 74° SEAL ADAPTER
PEHEL Hydraulic Model: P2J4
QTY:
45° ELBOW JIC MALE 74° CONE /JIC FEMALE 74° SEAL ADAPTER
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: PIPE ADAPTER
Thread Type 1: MALE JIC 74 CONE SEAL
Thread Type 2: FEMALE JIC 74 CONE SEAL
ABOUT THE ITEM:
1. P2J4 is 45° elbow adapter with JIC male 74° flare and swivel JIC female 74° seat, compliant with SAE J514 standard.
2. Full UNF thread sizes from 2J4-04 to 2J4-32 fit standard JIC flared tube hydraulic systems.
3. Carbon steel with zinc plating offers anti-rust, anti-vibration and reliable high-pressure sealing.
4. Dual hex flats enable easy wrench torque, flexible pipe routing to avoid pipeline interference.
5. Factory direct supply, precise 74° cone machining, supports bulk orders and custom hydraulic fittings.
