BSP Male O-Ring to Metric Female 74° Seat Hydraulic Adapter | Carbon Steel & Stainless Steel

PEHEL Hydraulic Model: 2GQ

QTY:

Material:Carbon steel
Brand:Pehel, OEM
Color: Silver
Connector Type: Straight
Thread Type: BSP Metric
Surface Treatment: CR3+ White Zinc Plated
About the item:
1.Standard transition – Combines BSP male O-ring with Metric female 74° seat for seamless system integration.
2.Leak-proof sealing – Integrated O-ring and precision 74° seat ensure zero leakage under high pressure.
3.Material versatility – Available in carbon steel for strength or stainless steel for superior corrosion resistance.
4.Surface protection – Silver zinc plating guards against rust and extends service life in harsh conditions.
5.Broad compatibility – Fits standard BSP and Metric hydraulic assemblies across industrial and mobile equipment.

PART NO.	THREAD E	THREAD F	O-RING E	A	B	L	S1	S2
2GQ-04-14	G1/4"×19	M14X1.5	7.65X1.78	10	8.5	28.5	19	19
2GQ-06-14	G3/8"×19	M14X1.5	13.94X2.62	11.5	8	28.5	22	19
2GQ-06-16	G3/8"×19	M16X1.5	13.94X2.62	11.5	8.5	29.5	22	22
2GQ-06-18	G3/8"×19	M18X1.5	13.94X2.62	11.5	8	30.5	22	24
2GQ-06-22	G3/8"×19	M22X1.5	13.94X2.62	11.5	10	31	22	27
2GQ-06-27	G3/8"×19	M27X1.5	13.94X2.62	11.5	10	36.5	27	32
2GQ-06-30	G3/8"×19	M30X1.5	13.94X2.62	11.5	11	36.5	30	36
2GQ-06-36	G3/8"×19	M36X2	13.94X2.62	11.5	13	37.5	34	41
2GQ-06-39	G3/8"×19	M39X2	13.94X2.62	11.5	13	39	38	46
2GQ-06-45	G3/8"×19	M45X2	13.94X2.62	11.5	15	41.5	46	55
2GQ-06-52	G3/8"×19	M52X2	13.94X2.62	11.5	17	43.5	50	60
2GQ-06-60	G3/8"×19	M60X2	13.94X2.62	11.5	20	46	60	70
2GQ-08-27	G1/2"×14	M27X1.5	17.12X2.62	14	10	39.5	27	32
2GQ-12-30	G3/4"×14	M30X1.5	23.47X2.62	15.5	11	41	32	36
2GQ-16-39	G1"×11	M39X2	29.74X3.53	18	13	47	41	46
2GQ-20-52	G1.1/4"×11	M52X2	37.69X3.53	20	17	54.5	50	60
