HOSE PART NO. HOSE I.D. HOSE O.D. MIN,BURST PERS, MAX.W.P. MIN,BEND,RAD, FERRULE mm mm Mpa Mpa mm 9806 9.53 15.62 27.6 6.9 25.4 P00710-06 9808 12.7 19.96 34.5 8.6 38 P00710-08 9810 16.0 23.03 38.6 9.6 50 P00710-10 9812 19.05 26.67 30.3 7.6 63 P00710-12 9816 24.4 32.25 27.6 6.9 76 P00710-16 9820 31.75 39.88 27.6 6.9 88.9 P00710-20 9824 38.10 45.97 20.7 5.2 114 P00710-24 9832 50.80 58.93 13.5 3.4 133 P00710-32
PEHEL | PTFE Hydraulic Hose, Smooth Bore with Stainless Steel Braid, High Temperature Chemical Resistant
PEHEL Hydraulic Model: PTFE Hose
QTY:
Type: PTFE Hydraulic Hose
Inner Tube: Smooth Bore PTFE
Reinforcement: Stainless Steel Wire Braid
Temperature Range: High Temperature Resistant
Material: PTFE Core, Stainless Steel Braid
Brand: PEHEL, OEM
1.PTFE hydraulic hose with a smooth bore inner tube, providing excellent flow characteristics and resistance to a wide range of chemicals.
2.Reinforced with a layer of stainless steel wire braid, offering high pressure containment and protection against abrasion and kinking.
3.Suitable for high temperature applications, withstanding continuous operating temperatures well above standard rubber hoses.
4.The chemically inert PTFE core resists degradation from aggressive fluids, acids, and solvents.
5.Manufactured to consistent tolerances for reliable performance in demanding hydraulic, chemical, and high temperature environments.
