PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A B C H S2 22691-04-04PK AST G1/4"X19 6 04 53 5 31 34 19 22691-06-06PK AST G3/8"X19 10 06 65.5 6.5 37 45 22 22691-08-08PK AST G1/2"X14 12 08 77 7.8 43 54 27 22691-10-10PK AST G5/8"X14 16 10 94.5 9 55.7 57 30 22691-12-12PK AST G3/4"X14 20 12 103 10.5 63.9 62.5 36 22691-16-16PK AST G1"X11 25 16 122 11 77.2 77.5 41
Pehel | Female 60 Degree Cone Seat BSPP Elbow One-Piece Hydraulic Hose Fitting
PEHEL Hydraulic Model: P22691-PK
QTY:
ISO 9001 passed female 60 degree cone seat bsp elbow one piece hydraulic hose fitting
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
About the item:
- 1.One-piece female 60° cone seat construction – no assembly joints means fewer leak paths in your BSPP hydraulic hose fitting system, holding secure under high working pressure.
- 2.BSPP parallel thread + 60° cone seat seal – the female cone seat mates with cone-ended fittings for a metal-to-metal, leak-free seal without extra washers.
- 3.Elbow design saves layout space – the 90° BSP elbow hydraulic fitting routes hoses neatly around tight machine frames, reducing bend stress and hose wear.
- 4.Corrosion-resistant finishes – silver color zinc plating on carbon steel, or full stainless steel options, keep this one-piece hydraulic fitting reliable in harsh environments.
- 5.ISO 9001 certified quality control – every female cone seat elbow hydraulic hose fitting is checked for thread accuracy and dimensional consistency before shipping.
