PEHEL丨Hydraulic Adapter – BSPT Male to JIS Metric Female 60° Cone Seal

PEHEL Hydraulic Model: 2TK-SP

QTY:

Material:Carbon steel
Brand:Pehel, OEM
Color: Silver
Connector Type: elbow
Thread Type: JIS Metric， BSPT
Surface Treatment: CR3+ White Zinc Plated
About the item:
· 1.Forged Construction: Ensures durability and strength for heavy-duty applications.
· 2.High Pressure Rating: Designed to withstand high-pressure hydraulic systems.
· 3. Zinc Plated Finish: Provides rust resistance and enhances longevity.
· 4. Strict tolerance crimp stem enables stable hose crimping, avoids hose pull-off & oil seepage.
· 5. Customizable Options: Available in various sizes and configurations for tailored solutions.

PART NO.	THREAD E	THREAD F	DIMENSIONS A	B	L	S1	S2
2TK-04-14SP	R1/4"X19	M14X1.5	14.5	10.5	29	17	19
2TK-06-14SP	R3/8"X19	M14X1.5	15	10.5	29.5	19	19
2TK-06-16SP	R3/8"X19	M16X1.5	15	9.3	30.5	19	22
2TK-06-18SP	R3/8"X19	M18X1.5	15	11.5	31.5	19	24
2TK-06-20SP	R3/8"X19	M20X1.5	15	12	32	19	27
2TK-08-20SP	R1/2"X14	M20X1.5	20	12	39	24	27
2TK-08-22SP	R1/2"X14	M22X1.5	20	14	39	24	27
2TK-08-24SP	R1/2"X14	M24X1.5	20	15.1	39.5	24	32
2TK-12-24SP	R3/4"X14	M24X1.5	20	15.1	41.5	30	32
2TK-12-30SP	R3/4"X14	M30X1.5	20	18	42.5	30	36
2TK-16-33SP	R1"X11	M33X1.5	25.5	21.3	47.5	36	41
2TK-20-36SP	R1.1/4"X11	M36X1.5	26.5	20	52	46	46
2TK-24-42SP	R1.1/2"X11	M42X1.5	26.5	18.8	55.5	50	55
