PART NO.
E (THREAD E)
HOSE BORE (DN)
HOSE BORE (DASH)
DIMENSIONS (A)
DIMENSIONS (B)
DIMENSIONS (S1)
Per hundred weight
Weight per case
20511-18-04TPK
M18X1.5
6
4
46.5
27.4
22
150
20511-18-06TPK
M18X1.5
10
6
49.5
28
22
100
20511-20-03TPK
M20X1.5
5
3
43
24.9
24
150
20511-20-06TPK
M20X1.5
10
6
51
29.5
24
100
20511-22-06TPK
M22X1.5
10
6
51.5
30
27
100
20511-24-08TPK
M24X1.5
12
8
57
29
30
16.9
20511-30-10TPK
M30X2
16
10
67.5
30.9
36
50
Metric Female 24° Cone O-ring L.T.
PEHEL Hydraulic Model: P20511 W-PK
QTY:
Metric Female 24 Degree Cone H. T. Hose Fitting
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:Metric Female Thread with 24° Cone O-ring Seal
- 1.This Metric Female 24° Cone O-ring L.T. hydraulic fitting adopts double cone o-ring seal to achieve zero leakage in medium pressure hydraulic circuits.
- 2.Standard metric female thread with 24° cone design makes this L.T. tube fitting compatible with common metric hydraulic tubing.
- 3.Light type compact body of Metric Female 24° Cone O-ring fitting saves installation space for narrow hydraulic equipment cabinets.
- 4.Silver zinc plating surface on Pehel L.T. cone fitting provides excellent rust resistance and extends pipeline service life.
- 5.Carbon steel & stainless steel options support OEM customization for metric 24 degree cone hydraulic tube assemblies.
