PEHEL/ 90 BSPT MALE/SAE MALE 90 CONE

PEHEL Hydraulic Model: 1TP9-SP

• 90 BSPT MALE/SAE MALE 90 CONE ADAPTER

• Material: Carbon steel

  Brand: Pehel, OEM

  Color: Silver

  Connector Type: ADAPTER

  Thread Type 1: BSPT MALE

  Thread Type 2: SAE MALE

• About the item:

• 1. 90-degree right-angle transition elbow specially designed to connect European BSPT taper thread systems and American SAE 90° cone hydraulic pipelines, solving layout restrictions in compact hydraulic equipment and realizing cross-standard conversion.
• 2. Double reliable sealing structure: BSPT (R taper male, 55° thread angle) relies on taper thread sealing with PTFE tape; SAE male end adopts standard 90° metal-to-metal cone line contact seal, delivering stable leak-proof performance under medium and high pressure, vibration and hydraulic pulsation.
• 3. Complete size specifications including straight equal-size and reducing transition models, covering mainstream thread combinations such as R1/4", R3/8", R1/2" matched with 5/8" SAE thread; all dimension parameters (A, B, S1) follow unified standards for full interchangeability.
• 4. Constructed from high-strength carbon steel with precision CNC thread cutting and uniform zinc-plated anti-corrosion finish, reaching long salt spray resistance to prevent rust in humid, dusty and harsh industrial working environments. Integrated hexagonal wrench flats allow easy torque control during assembly and disassembly without damaging sealing surfaces.
• 5. Widely compatible with mixed-standard hydraulic machinery including European excavators, American injection molding machines, agricultural equipment and hydraulic power units, optimizing hose routing to reduce bending stress and extend overall pipeline service life with outstanding cost performance.
