PART NO. THREAD O-RING DIMENSIONS E F F A B S1 S2 1TH9-02-10OG R1/8"X28 M10X1 8.1X1.6 21 26.5 11 14 1TH9-02-12OG R1/8"X28 M12X1.5 9.3X2.4 21 32 11 17 1TH9-04-12OG R1/4"X19 M12X1.5 9.3X2.4 25.5 32 14 17 1TH9-04-14OG R1/4"X19 M14X1.5 11.3X2.4 25.5 32 14 19 1TH9-04-18OG R1/4"X19 M18X1.5 15.3X2.4 28 37 19 24 1TH9-06-14OG R3/8"X19 M14X1.5 11.3X2.4 28.5 34 16 19 1TH9-06-16OG R3/8"X19 M16X1.5 13.3X2.4 28.5 34.8 16 22 1TH9-08-18OG R1/2"X14 M18X1.5 15.3X2.4 36 39.5 22 24 1TH9-08-20OG R1/2"X14 M20X1.5 17.3X2.4 36 40 22 27 1TH9-08-22OG R1/2"X14 M22X1.5 19.3X2.4 36 40.2 22 27 1TH9-12-22OG R3/4"X14 M22X1.5 19.3X2.4 43.5 43.5 27 27 1TH9-12-27OG R3/4"X14 M27X2 23.5X3 43.5 48.5 27 32 1TH9-16-27OG R1"X11 M27X2 23.5X3 50 52 33 32 1TH9-16-33OG R1"X11 M33X2 29.2X3 50 52.5 33 41 1TH9-20-42OG R1.1/4"X11 M42X2 38.5X3 56.5 57.2 41 50 1TH9-24-48OG R1.1/2"X11 M48X2 44.5X3 62.5 62.7 48 55
PEHEL/90 BSPT MALE/METRIC MALE O-RING
PEHEL Hydraulic Model: 1TH9-OG
QTY:
90 BSPT MALE/METRIC MALE O-RING
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: elbow adapter
Thread Type 1: BSPT MALE
Thread Type 2: METRIC MALE O-RING
About the item:
1. 1TH9‑OG is 90‑degree elbow hydraulic adapter with BSPT male tapered thread and metric male O‑ring boss end.
2. Metric‑side O‑ring face‑seal delivers reliable leak‑proof performance complying with ISO 6149‑2 for high‑pressure hydraulic circuits.
3. Comprehensive size selection covers R1/8"‑R1‑1/2" BSPT and corresponding M10×1‑M48×2 metric thread specifications.
4. Precisely CNC‑machined carbon‑steel body with zinc‑plated finish, featuring good interchangeability and corrosion resistance.
5. Angled 90‑degree layout optimizes piping routing, widely used for cross‑standard transition in mobile and industrial hydraulic equipment.
