PART NO. THREAD DIMENSIONS E F A B S1 1T4-02SP R1/8"X28 R1/8"X28 17 17 11 1T4-04SP R1/4"X19 R1/4"X19 21 21 14 1T4-04-06SP R1/4"X19 R3/8"X19 21 23 16 1T4-06SP R3/8"X19 R3/8"X19 23 23 16 1T4-06-08SP R3/8"X19 R1/2"X14 25 29.5 22 1T4-08SP R1/2"X14 R1/2"X14 29.5 29.5 22 1T4-08-12SP R1/2"X14 R3/4"X14 30 30.5 27 1T4-12SP R3/4"X14 R3/4"X14 30.5 30.5 27 1T4-12-16SP R3/4"X14 R1"X11 32.5 38 33 1T4-16SP R1"X11 R1"X11 38 38 33 1T4-16-20SP R1"X11 R1.1/4"X11 42 43 41 1T4-20SP R1.1/4"X11 R1.1/4"X11 43 43 41 1T4-24SP R1.1/2"X11 R1.1/2"X11 47.5 47.5 48 1T4-32SP R2"X11 R2"X11 53 53 63
Pehel/1T4-SP/Hydraulic Male BSPT 45° Elbow Connector/All Sizes Available
PEHEL Hydraulic Model: 1T4-SP
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: elbow
Thread Type: BSPT
About the item:
1.Full through-bore design maintains consistent internal flow diameter, avoiding flow restriction that causes system heat rise and efficiency loss.
2.Chamfered tube entry guides tubing for error-free assembly, reducing installation misalignment that leads to premature seal wear.
3.Wide operating temperature range from -40℃ to +120℃, stable performance in extreme cold northern mines and high-temperature metallurgy workshops.
