THREAD DIMENSIONS PART NO. E F A B S1 S2 6B9-04 G1/4"X19 G1/4"X19 25 51 16 19 6B9-06 G3/8"X19 G3/8"X19 29 53.5 19 22 6B9-08 G1/2"X14 G1/2"X14 34.5 58.5 22 27 6B9-12 G3/4"×14 G3/4"×14 41 64 30 32 6B9-16 G1"×11 G1"×11 47.5 71 33 41
PEHEL / 90°ELBOW BSP MALE 60 ° SEAT BULKHEAD
PEHEL Hydraulic Model: P6B9/P6B9-LN
QTY:
90° ELBOW BSP MALE 60 ° SEAT BULKHEAD
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: BULKHEAD
Thread Type: BSP MALE 60 ° SEAT
About the item:
1. 90° Elbow BSP Male 60° Seat Bulkhead — through-wall elbow with BSP male thread for panel or tank mounting.
2. 60° cone seat ensures a reliable, leak-tight metal-to-metal seal under pressure.
3. 90° design saves space and reduces hose stress in compact hydraulic layouts.
4. Precision-machined carbon steel construction delivers high strength and long service life.
5. Widely used in hydraulic, pneumatic, oil and gas systems for secure through-panel connections.
