THREAD DIMENSIONS PART NO. E F A B L S1 S2 2J-04 7/16"X20 7/16"X20 14 9.5 28 12 17 2J-04-05 7/16"X20 1/2"X20 14 9 28.5 12 19 2J-04-06 7/16"X20 9/16"X18 14 9.5 28.5 14 19 2J-04-08 7/16"X20 3/4"X16 14 10.8 30.5 19 24 2J-05 1/2"X20 1/2"X20 14 9 29 14 19 2J-05-06 1/2"X20 9/16"X18 14 9.5 29.5 14 19 2J-05-08 1/2"X20 3/4"X16 14 10.8 30.5 19 24 2J-06 9/16"X18 9/16"X18 14.1 9.5 29 17 19 2J-06-08 9/6"X18 3/4"X16 14.1 10.8 31 19 24 2J-06-10 9/16"X18 7/8"X14 14.1 12 33.5 22 27 2J-08 3/4"X16 3/4"X16 16.7 10.8 36 22 24 2J-08-06 3/4"X16 9/16"X18 16.7 9.5 34 22 19 2J-08-10 3/4"X16 7/8"X14 16.7 12 36.5 22 27 2J-08-12 3/4"X16 1.1/16"X12 16.7 13 39.5 27 32 2J-10 7/8"X14 7/8"X14 19.3 12 39 24 27 2J-10-08 7/8"X14 3/4"X16 19.3 10.8 38 24 24 2J-10-12 7/8"X14 1.1/16"X12 19.3 13 42 27 32 2J-12 1.1/16"X12 1.1/16"X12 21.9 13 44.5 30 32 2J-12-10 1.1/16"X12 7/8"X14 21.9 12 43.5 30 27 2J-12-16 1.1/16"X12 1.5/16"X12 21.9 14 45.5 36 41 2J-16 1.5/16"X12 1.5/16"X12 23.1 14 46.5 36 41 2J-16-20 1.5/16"X12 1.5/8"X12 23.1 15 50 41 50 2J-20 1.5/8"X12 1.5/8"X12 24.3 15 52 46 50 2J-20-24 1.5/8"X12 1.7/8"X12 24.3 19 52 46 55 2J-24 1.7/8"X12 1.7/8"X12 27.5 19 57 50 55 2J-24-32 1.7/8"X12 2.1/2"X12 27.5 23.5 59.6 65 75 2J-32 2.1/2"X12 2.1/2"X12 33.9 23.5 66 65 75
JIC Male 74° Cone to JIC Female Adapter – Hydraulic Adapter
PEHEL Hydraulic Model: P2J
QTY:
Material:Carbon steel
Brand:Pehel, OEM
Color: Silver
Connector Type: Straight Adapter
Thread Type: JIC
Surface Treatment: CR3+ White Zinc Plated
About the item:
1.Standardized JIC Compatibility: Engineered with JIC male 74° cone and JIC female 74° seat, strictly conforming to SAE J514 standards for reliable interconnection across North American hydraulic systems.
2. Superior Sealing Performance: The precision-machined 74° flare interface creates a metal-to-metal seal that prevents leakage under extreme pressure and high-temperature conditions.
3. Flexible Material Options: Available in durable carbon steel for general industrial use or stainless steel for corrosive environments like marine and chemical processing.
4.Corrosion-Resistant Finish: Coated with silver zinc plating, this fitting offers enhanced protection against rust, extending service life in harsh outdoor or washdown environments.
5.Custom Branding Support: Offered under the trusted Pehel brand or customized through our OEM services to meet your specific size and packaging requirements.
