PART NO. THREAD DIMENSIONS E F A L S1 5TB-02-04SP R1/8"X28 G1/4"X19 10 31.5 19 5TB-04SP R1/4"X19 G1/4"X19 14.5 35 19 5TB-04-06SP R1/4"X19 G3/8"X19 14.5 38.5 22 5TB-06SP R3/8"X19 G3/8"X19 15 39 22 5TB-06-08SP R3/8"X19 G1/2"X14 15 43 27 5TB-08SP R1/2"X14 G1/2"X14 20 48 27 5TB-08-12SP R1/2"X14 G3/4"X14 20 50 36 5TB-12SP R3/4"X14 G3/4"X14 20 49 36 5TB-12-16SP R3/4"X14 G1"X11 20 54.5 41 5TB-16SP R1"X11 G1"X11 25.5 60 41 5TB-16-20SP R1"X11 G1.1/4"X11 25.5 61.5 50 5TB-20SP R1.1/4"X11 G1.1/4"X11 26.5 61.5 50 5TB-24SP R1.1/2"X11 G1.1/2"X11 26.5 63 55
Pehel | P5TB | Hydraulic BSPT Male/BSP Female Reducer Hose Adapter
PEHEL Hydraulic Model: 5TB-SP
QTY:
Material: Carbon steel
Brand: Pehel
Color: Silver
Thread: BSPT/BSPT
Connector: Reducer
Size: 1/4"-2"
About the item:
1. Versatile adapter – connects BSPP and BSPT threaded systems seamlessly.
2. BSP thread compatibility – parallel thread with O-ring for leak-proof sealing.
3. BSPT thread option – tapered thread provides self-sealing metal-to-metal fit.
4. Durable steel body – corrosion-resistant for high-pressure durability.
5. Easy installation – thread-on design saves assembly time.
