PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH C S2 H Per hundred weight Weight per case P22691-02-03 G1/8"-28 4 3 5.5 14 31.5 2.4 350 P22691-02-04 G1/8"-28 6 4 5.5 14 34.5 3.4 350 P22691-04-03 G1/4"-19 4 3 5.5 19 33.5 3.8 250 P22691-04-04 G1/4"-19 6 4 5.5 19 36.5 4.3 250 P22691-04-05 G1/4"-19 8 5 5.5 19 39.5 5.4 200 P22691-04-06 G1/4"-19 10 6 5.5 19 36.5 7.9 200 P22691-06-04 G3/8"-19 6 4 6.3 22 37.7 6 125 P22691-06-05 G3/8"-19 8 5 6.3 22 40.7 6.8 125 P22691-06-06 G3/8"-19 10 6 6.3 22 43 7.8 125 P22691-08-06 G1/2"-14 10 6 7.5 27 45.8 12 100 P22691-08-08 G1/2"-14 12 8 7.5 27 51 14 70 P22691-08-10 G1/2"-14 16 10 7.5 27 55.5 22.6 60 P22691-10-08 G5/8"-14 12 8 9.5 30 51.5 16.8 100 P22691-10-10 G5/8"-14 16 10 9.5 30 56 21 100 P22691-12-08 G3/4"-14 12 8 10.9 32 52.1 18.1 40 P22691-12-10 G3/4"-14 16 10 10.9 32 56.6 22.5 80
Pehel/22691/90deg Elbow Female BSP 60deg Cone Hydraulic Hose Fitting/Stock Item
PEHEL Hydraulic Model: P22691
QTY:
90 Elbow Tube Fitting BSP Hydraulic Fitting Female Pipe Fittings 22691
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Elbow
Thread Type: bsp 60deg cone
About the item:
1.Full through-bore design maintains consistent internal flow diameter, avoiding flow restriction that causes system heat rise and efficiency loss.
2.Wide operating temperature range from -40℃ to +120℃, stable performance in extreme cold northern mines and high-temperature metallurgy workshops.
3.Durable & Corrosion-Resistant: Made of carbon steel/stainless steel with surface treatments, extending service life.
