PART NO. THREAD CAPTIVE DIMENSIONS E F F A B L S1 1B-02WD G1/8"X28 G1/8"X28 WD-B02 10 8 25.5 14 1B-02-04WD G1/8"X28 G1/4"X19 WD-B04 10 12 30 19 1B-02-06WD G1/8"X28 G3/8"X19 WD-B06 10 12 32.5 22 1B-02-08WD G1/8"X28 G1/2"X14 WD-B08 10 14 37 27 1B-04WD G1/4"X19 G1/4"X19 WD-B04 12 12 32 19 1B-04-02WD G1/4"X19 G1/8"X28 WD-B02 12 8 27.5 19 1B-04-06WD G1/4"X19 G3/8"X19 WD-B06 12 12 34.5 22 1B-04-08WD G1/4"X19 G1/2"X14 WD-B08 12 14 39 27 1B-06WD G3/8"X19 G3/8"X19 WD-B06 13.5 12 34 22 1B-06-04WD G3/8"X19 G1/4"X19 WD-B04 13.5 12 33.5 22 1B-06-08WD G3/8"X19 G1/2"X14 WD-B08 13.5 14 40.5 27 1B-06-12WD G3/8"X19 G3/4"X14 WD-B12 13.5 16 43.5 32 1B-08WD G1/2"X14 G1/2"X14 WD-B08 16 14 43 27 1B-08-06WD G1/2"X14 G3/8"X19 WD-B06 16 12 40.5 27 1B-08-12WD G1/2"X14 G3/4"X14 WD-B12 16 16 46 32 1B-08-16WD G1/2"X14 G1"X11 WD-B16 16 18 50 41 1B-10-12WD G5/8"X14 G3/4"X14 WD-B12 17.5 16 45.5 32 1B-10-16WD G5/8"X14 G1"X11 WD-B16 17.5 18 51.5 41 1B-12WD G3/4"X14 G3/4"X14 WD-B12 18.5 16 46.5 32 1B-12-08WD G3/4"X14 G1/2"X14 WD-B08 18.5 14 44.5 32 1B-12-16WD G3/4"X14 G1"X11 WD-B16 18.5 18 52.5 41 1B-12-20WD G3/4"X14 G1.1/4"X11 WD-B20 18.5 20 56.5 50 1B-12-24WD G3/4"X14 G1.1/2"X11 WD-B24 18.5 22 58.5 55 1B-16WD G1"X11 G1"X11 WD-B16 20.5 18 54.5 41 1B-16-12WD G1"X11 G3/4"X14 WD-B12 20.5 16 52.5 41 1B-16-20WD G1"X11 G1.1/4"X11 WD-B20 20.5 20 58.5 50 1B-16-24WD G1"X11 G1.1/2"X11 WD-B24 20.5 22 60.5 55 1B-20WD G1.1/4"X11 G1.1/4"X11 WD-B20 20.5 20 58.5 50 1B-20-16WD G1.1/4"X11 G1"X11 WD-B16 20.5 18 56.5 50 1B-20-24WD G1.1/4"X11 G1.1/2"X11 WD-B24 20.5 22 60.5 55 1B-24WD G1.1/2"X11 G1.1/2"X11 WD-B24 23 22 63 55 1B-32WD G2"X11 G2"X11 WD-B32 25.5 22 66.5 75
Pehel | BSP Male 60 Seat / BSP Male Captive Seal Hydraulic Adapter
PEHEL Hydraulic Model: 1B-WD
QTY:
- Standard: BSP thread standard
- Material: Carbon steel, stainless steel
- Brand: Pehel, OEM available
- Surface Finish: Silver zinc plating, Chrome plating, Nickel plating
- Connector Type: BSP Male
- Thread Type: BSPP / BSPT customizable
- Feature: 60 degree seat, captive seal, leak-proof, high pressure resistance
- Application: Hydraulic piping, hydraulic hose assembly
About the item:
- 1.This BSP male hydraulic adapter comes with 60 seat design to ensure tight metal-to-metal sealing.
- 2.Built-in captive seal of our BSP male adapter prevents seal loss during assembly and disassembly.
- 3.Available in carbon steel or stainless steel with multiple plating options for anti-corrosion protection.
- 4.Pehel BSP captive seal adapter delivers stable leak-free performance under high hydraulic pressure.
- 5.Custom BSP thread types are supported, ideal to connect hydraulic hoses and hydraulic components.
- 6.OEM service offered, this BSP male 60 seat adapter fits various industrial hydraulic systems.
