90°JIC Compact Female 74° Cone Seat

90°JIC Compact Female 74° Cone Seat

PEHEL Hydraulic Model: P26791K

QTY:

90d Elbow Female Jic One Piece Hydraulic Hose Fitting 26791-Pkast

  • 90°JIC Compact Female 74° Cone Seat Specification
  • You May Also Like
  • PART NO. tdREAD E HOSE BORE DIMENSIONS
    DN DASH A C H S1 S2 Per hundred weight Weight per case
    P26791K-04-04PO 7/16"X20 6 4 11.7 9 18 11 17 200
    P26791K-06-04PO 9/16"X18 6 4 14 10.5 20.5 14 19 200
    P26791K-06-06PO 9/16"X18 10 6 15.5 10.5 21 16 19 100
    P26791K-08-06PO 3/4"X16 10 6 16 11 22.5 16 24 80
    P26791K-08-08PO 3/4"X16 12 8 15.7 11 22.5 19 24 60
    P26791K-10-10PO 7/8"X14 16 10 18.5 12 27.5 22 27 100
    P26791K-12-12PO 1.1/16"X12 20 12 21.5 15 30 27 32 70
