PART NO. BOLT HOSE BORE DIMENSIONS DN DASH A d D H 72011-02-03 G1/8"X28 5 03 18.5 9.9 22 16 72011-02-04 G1/8"X28 6 04 18.5 9.9 24 16 72011-04-03 G1/4"X19 5 03 19 13.3 24 15 72011-04-04 G1/4"X19 6 04 19.5 13.3 24 15 72011-04-05 G1/4"X19 8 05 19 13.3 24 15 72011-04-06 G1/4"X19 10 06 19.5 13.3 24 15 72011-06-04 G3/8"X19 6 04 22 16.7 29 20 72011-06-05 G3/8"X19 8 05 22 16.7 29 20 72011-06-06 G3/8"X19 10 06 22 16.7 29 20 72011-06-08 G3/8"X19 12 08 22.5 16.7 29 20 72011-08-05 G1/2"X14 8 05 27.5 21 38 25 72011-08-06 G1/2"X14 10 06 27.5 21 38 25 72011-08-08 G1/2"X14 12 08 28 21 38 25 72011-08-10 G1/2"X14 16 10 29 21 38 25 72011-10-10 G5/8"X14 16 10 28 23 40 27 72011-12-10 G3/4"X14 16 10 31.5 26.5 48 31 72011-12-12 G3/4"X14 20 12 32 26.5 48 31 72011-16-08 G1"X11 12 8 40 33.3 60 42 72011-16-12 G1"X11 20 12 41 33.3 60 42 72011-16-16 G1"X11 25 16 41 33.3 60 42 NOTE:1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 72012-XX-XX。
PEHEL/BSP Banjo
PEHEL Hydraulic Model: P72011
QTY:
Bsp Hose Banjo Hydraulic Hose Connector Fitting
BSP Banjo
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: BANJO
Thread Type: BSP BANJO
ABOUT THE ITEM:
- 1.Model P72011 is BSP banjo hose fitting specially designed for braided hydraulic hose assemblies.
- 2.Wide size coverage includes multiple BSP thread specifications and hose bore DN5‑DN25 for diverse selection.
- 3.Banjo‑style spherical structure enables flexible hose orientation and reduces hose torsion stress during installation.
- 4.Precisely CNC‑machined carbon‑steel body with zinc‑plated finish for good interchangeability and corrosion resistance.
- 5.Compact connection solution, widely applied for confined‑space piping in industrial and mobile hydraulic equipment.
