PARTNO. THREAD O-RING DIMENSIONS E F E F A B L S1 1G-02 G1/8"X28 G1/8"X28 7.65X1.78 7.65X1.78 9.5 9.5 28.5 14 1G-04 G1/4"X19 G1/4"X19 10.77X2.62 10.77X2.62 10 10 30 19 1G-06 G3/8"X19 G3/8"X19 13.94X2.62 13.94X2.62 11.5 11.5 33.5 22 1G-08 G1/2"X14 G1/2"X14 17.12X2.62 17.12X2.62 14 14 42 27 1G-12 G3/4"X14 G3/4"X14 23.47X2.62 23.47X2.62 15.5 15.5 46 32 1G-16 G1"X11 G1"X11 29.74X3.53 29.74X3.53 18 18 54.5 41 1G-20 G1.1/4"X11 G1.1/4"X11 37.69X3.53 37.69X3.53 20 20 61 50 1G-24 G1.1/2"X11 G1.1/2"X11 44.04X3.53 44.04X3.53 21.5 21.5 64 55
Pehel | 1G BSP Male O-Ring Hydraulic Fittings Zinc Plated Steel Adapters
PEHEL Hydraulic Model: 1G
QTY:
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type: Straight
Thread Type:
- About the item:
- 1.Our Pehel 1G BSP male o-ring fitting adopts built-in o-ring structure for superior leakproof sealing effect.
- 2.This BSP male hydraulic connector is manufactured from carbon steel and stainless steel with anti-rust zinc plating.
- 3.Standard 1G structure perfectly matches o-ring seal, effectively avoiding oil leakage in hydraulic pipelines.
- 4.Precisely processed BSP male thread on zinc plated steel adapter ensures tight and fast installation.
- 5.Industrial grade 1G o-ring hydraulic fitting withstands high pressure for machinery hydraulic systems.
