PART NO. THREAD DIMENSIONS E F A B L S1 S2 2BF-04 G1/4"X19 9/16"X18 12 8.5 33.5 19 19 2BF-04-06 G1/4"X19 11/16"X16 12 10 36.5 19 22 2BF-06 G3/8"X19 11/16"X16 13.5 10 40 22 22 2BF-06-08 G3/8"X19 13/16"X16 13.5 11 42 22 27 2BF-08-06 G1/2"X14 11/16"X16 16 10 44.5 27 22 2BF-08 G1/2"X14 13/16"X16 16 11 46.5 27 27 2BF-08-10 G1/2"X14 1"X14 16 13.5 50.5 27 30 2BF-10 G5/8"X14 1"X14 17.5 13.5 52 30 30 2BF-12-10 G3/4"X14 1"X14 18.5 13.5 54 32 30 2BF-12 G3/4"X14 1.3/16"X12 18.5 15 55.5 32 36 2BF-16-12 G1"X11 1.3/16"X12 20.5 15 59.5 41 36 2BF-16 G1"X11 1.7/16"X12 20.5 15 60.5 41 41 2BF-20 G1.1/4"X11 1.11/16"X12 20.5 15 63 50 50 2BF-20-16 G1.1/4"X111 1.7/16"X12 20.5 15 63.5 50 41 2BF-24 G1.1/2"X11 2"X12 23 14.8 68 50 60
PEHEL/BSP MALE 60 SEAT/ORFS FEMALE ADAPTER CONNECTOR
PEHEL Hydraulic Model: 2BF
QTY:
BSP MALE 60 SEAT/ORFS FEMALE ADAPTER CONNECTOR
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: PIPE ADAPTER
Thread Type 1: MALE BSPP 60 CONE
Thread Type 2: FEMALE ORFS
ABOUT THE ITEM:
1.PEHEL 2BF hydraulic transition adapter combines BSP male 60° cone seat (ISO 228-1) and ORFS female O-ring face seal (SAE J1453), seamlessly connects European BSP and American ORFS hydraulic pipeline standards.
2.Full complete size lineup from 2BF-04 to 2BF-24 covers mainstream G parallel threads and UN ORFS specs, unified A/B/L/S1/S2 dimensional standards for cross-brand quick interchange.
3.CNC precision machined carbon steel with zinc electroplated surface delivers outstanding anti-rust, anti-vibration performance, maintains zero-leak flat-face sealing under long-term high-pressure hydraulic operation.
4.Dual hex wrench flats S1 & S2 design enables convenient torque tightening during assembly, effectively avoids thread loosening and oil seepage for mobile machinery, construction and industrial hydraulic systems.
5.Factory direct supply 2BF BSP to ORFS fitting with strict thread tolerance inspection, supports bulk wholesale, OEM custom dimension processing and fast delivery for global hydraulic fitting distributors.
