PART NO. THREAD COPPER WASHER DIMENSIONS E F F A B L S1 S2 2B-02-04G G1/8"X28 G1/4"X19 DP-B04G 11 14.5 25.5 14 19 2B-04G G1/4"X19 G1/4"X19 DP-B04G 12 14.5 26.5 19 19 2B-04-08G G1/4"X19 G1/2"X14 DP-B08G 12 20 29 19 27 2B-06-04G G3/8"X19 G1/4"X19 DP-B04G 13.5 14.5 30 22 19 2B-08-04G G1/2"X14 G1/4"X19 DP-B04G 16 14.5 34.5 27 19 2B-08G G1/2"X14 G1/2"X14 DP-B08G 16 20 37 27 27
PEHEL/ BSP MALE 60 SEAT/BSP PRESSURE GAUGE CONNECTORS
PEHEL Hydraulic Model: 2B-G
QTY:
BSP MALE 60 SEAT/BSP PRESSURE GAUGE CONNECTORS
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: ADAPTER
Thread Type 1: BSP MALE 60 SEAT
Thread Type 2: BSP PRESSURE GAUGE
ABOUT THE ITEM:
1. Model 2B‑G is BSP pressure‑gauge connector with BSP male 60° seat and BSP female thread for gauge installation.
2. Matched copper washer ensures tight leak‑proof sealing for hydraulic pressure measuring circuits.
3. Multiple BSP thread sizes from G1/8" to G1/2" for diverse pressure gauge and port matching demands.
4. Precisely CNC‑machined carbon‑steel body with zinc‑plated finish for corrosion resistance and good interchangeability.
5. Compact adapter dedicated for pressure gauge mounting, widely applied on industrial and mobile hydraulic equipment.
