PART NO. THREAD O-RING DIMENSIONS E F G F A,C B S1 S2,S4 S3 EBGB-04OG G1/4"X19 G1/4"X19 G1/4"X19 10.77X2.62 5.5 31.8 14 19 19 EBGB-06OG G3/8"X19 G3/8"X19 G3/8"X19 13.94X2.62 6.3 36.8 19 22 22 EBGB-08OG G1/2"X14 G1/2"X14 G1/2"X14 17.12X2.62 7.5 43.2 22 27 27 EBGB-10OG G5/8"X14 G5/8"X14 G5/8"X14 19.18X2.46 9.5 44.5 22 30 30 EBGB-12OG G3/4"X14 G3/4"X14 G3/4"X14 23.47X2.62 10.9 49.3 27 32 32 EBGB-16OG G1"X11 G1"X11 G1"X11 29.74X3.53 11.7 53 33 41 41
Pehel/EBGB-OG/Female Swivel BSP-Male BSP O-Ring-Female BSP Swivel Tee Adapter
PEHEL Hydraulic Model: EBGB-OG
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Tee
Thread Type: BSP 60° Cone/BSP O-Ring
About the item:
1.Hardened carbon steel body with anti-rust coating, resists vibration and harsh industrial environments for long service life.
2.Fully compliant with ISO, SAE and DIN standards, quick to install without extra sealant.
3.Wide size range from 1/4" to 2", compatible with most hydraulic hoses on the market.
4.Premium hydraulic tee fitting, perfect for construction machinery, agricultural equipment and automation lines.
