PART NO. THREAD DIMENSIONS E F G A,B,C S1 S2,S3,S4 DA-02 G1/8"X28 G1/8"X28 G1/8"X28 2 11 14 DA-04 G1/4"X19 G1/4"X19 G1/4"X19 4 11 19 DA-06 G3/8"X19 G3/8"X19 G3/8"X19 5 14 22 DA-08 G1/2"X14 G1/2"X14 G1/2"X14 5 19 27 DA-12 G3/4"X14 G3/4"X14 G3/4"X14 9 24 32 DA-16 G1"X11 G1"X11 G1"X11 10.5 30 41 DA-20 G1.1/4"X11 G1.1/4"X11 G1.1/4"X11 10 41 50 DA-24 G1.1/2"X11 G1.1/2"X11 G1.1/2"X11 11 48 55
PEHEL/BSP FEMALE MULTISEAL
PEHEL Hydraulic Model: DA
QTY:
BSP FEMALE MULTISEAL
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: TEE
Thread Type: BSP FEMALE MULTISEAL
ABOUT THE ITEM:
1. DA is three‑way tee hydraulic fitting with triple BSP female multiseal 60° cone ports for pipeline flow branching.
2. Multiseal 60‑degree cone sealing delivers reliable leak‑proof performance under high‑pressure hydraulic working conditions.
3. Complete BSP thread sizes range from G1/8" up to G1‑1/2", covering most common British‑standard hydraulic port specifications.
4. Precisely CNC‑machined carbon‑steel body with zinc‑plated finish, ensuring good interchangeability and corrosion resistance.
5. Compact tee‑branch layout, widely used for manifold assembly on industrial and mobile hydraulic machinery systems.
