PART NO. THREAD O-RING DIMENSIONS E F E A B S1 S2 2GB4-02OG G1/8"X28 G1/8"X28 7.65X1.78 24 5.5 11 14 2GB4-04-02OG G1/4"X19 G1/8"X28 10.77X2.62 27 5.5 14 14 2GB4-04-06OG G1/4"X19 G3/8"X19 10.77X2.62 27 6.3 14 22 2GB4-06OG G3/8"X19 G3/8"X19 13.94X2.62 30 6.3 16 22 2GB4-06-04OG G3/8"X19 G1/4"X19 13.94X2.62 30 5.5 16 19 2GB4-06-08OG G3/8"X19 G1/2"X14 13.94X2.62 31 7.5 19 27 2GB4-08OG G1/2"X14 G1/2"X14 17.12X2.62 36 7.5 22 27 2GB4-08-06OG G1/2"X14 G3/8"X19 17.12X2.62 36 6.3 22 22 2GB4-08-10OG G1/2"X14 G5/8"X14 17.12X2.62 36 9.5 22 30 2GB4-08-12OG G1/2"X14 G3/4"X14 17.12X2.62 36.5 10.9 24 32 2GB4-12OG G3/4"X14 G3/4"X14 23.47X2.62 42 10.9 27 32 2GB4-12-08OG G3/4"X14 G1/2"X14 23.47X2.62 42 7.5 27 27 2GB4-12-16OG G3/4"X14 G1"X11 23.47X2.62 42.8 11.7 30 41 2GB4-16OG G1"X11 G1"X11 29.74X3.53 44 11.7 33 41 2GB4-16-12OG G1"X11 G3/4"X14 29.74X3.53 44 10.9 33 32 2GB4-20OG G1.1/4"X11 G1.1/4"X11 37.69X3.53 47.5 11 41 50 2GB4-20-16OG G1.1/4"X11 G1"X11 37.69X3.53 47.5 11.7 41 41 2GB4-24OG G1.1/2"X11 G1.1/2"X11 44.04X3.53 51.5 13 48 55
Pehel | 45 Degree BSP Male Hydraulic Fittings O-Ring & 60° Cone Seat Zinc Plated Adapters
PEHEL Hydraulic Model: 2GB4-OG
QTY:
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
- About the item:
- 1.Our Pehel 45 degree BSP male fitting integrates O-ring seal and standard 60° cone seat dual connection design.
- 2.This BSP male o-ring connector is crafted from carbon steel & stainless steel with anti-rust silver zinc plating.
- 3.Standard 60° cone seat structure on 45° BSP male adapter delivers tight sealing and zero hydraulic oil leakage.
- 4.Precisely machined BSP male threads on zinc plated hydraulic fitting ensure quick assembly and stable high-pressure work.
- 5.Compact 45 degree bent design of BSP male o-ring connector fits narrow pipeline installation spaces perfectly.
