Home    >     Hydraulic Adapter    >    British Standard    >     BSP Thread 60 Cone Fittings    >     45 BSP MALE 60 SEAT/BSP PRESSURE GAUGE CONNECTOR

45 BSP MALE 60 SEAT/BSP PRESSURE GAUGE CONNECTOR

Model: 2B4-G

QTY:

  • You May Also Like

  • PART NO THREAD COPPERWASHER DIMENSIONS
    E F F A B S1 S2
    2B4-02-04G G1/8"X28 G1/4"X19 DP-B04G 20 14.5 14 19
    2B4-04G G1/4"X19 G1/4"X19 DP-B04G 20.3 14.5 14 19
    2B4-04-08G G1/4"X19 G1/2"X14 DP-B08G 23 20 19 27
    2B4-06-04G G3/8"X19 G1/4"X19 DP-B04G 22 14.5 16 19
    2B4-08-04G G1/2"X14 G1/4"X19 DP-B04G 27 14.5 19 19
    2B4-08G G1/2"X14 G1/2"X14 DP-B08G 27 20 22 27
