PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A C H S2 22291-04-04 G1/4"X19 6 04 30 7.5 34.5 19 22291-06-06 G3/8"X19 10 06 35 9.5 41 22 22291-08-08 G1/2"X14 12 08 41 11.3 48 27 22291-12-12 G3/4"X14 20 12 65.5 13 63.5 32 22291-16-16 G1"X11 25 16 69.7 14 70 41 22291-20-20 G1.1/4"X11 32 20 88.5 15.5 82.5 50 22291-24-24 G1.1/2"X11 40 24 109.5 17.5 97.5 55 NOTE:1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 22292-XX-XX。
Pehel | BSP Female Flat‑Seat 90° Elbow Hydraulic Hose End Fitting
PEHEL Hydraulic Model: P22291
QTY:
BSP female flat seat 90 degree elbow bsp hose fittings galvanized steel fittings hydraulic tube fittings
- Material: Carbon steel, stainless steel
- Brand: Pehel, OEM
- Color: Silver color zinc plating / galvanized finish
- Connector Type: 90° Elbow, Hose Crimp End, BSP Female Flat‑Seat
- Thread Type: BSP Female thread ISO 1179‑1, flat seat sealing face
- Surface Treatment: Trivalent zinc plating, galvanized silver finish
- Sealing Type: Flat‑seat face sealing
- Angle: 90 Degree
- Standard: ISO 1179‑1
About the item:
- 1.This 90° elbow hose crimp end with BSP female flat‑seat is specially designed for hydraulic hose crimp assembly.
- 2.Carbon steel and stainless steel options make this hose nipple suitable for varied pressure and working environments.
- 3.Galvanized zinc‑plated surface delivers excellent anti‑corrosion performance for this heavy‑duty hose coupling.
- 4.Precision machined BSP thread and flat‑seat face guarantee leak‑tight performance for high‑pressure hose assembly joint.
- 5.Offer Pehel standard stocks and OEM customization to match your dedicated fluid hose connection component requirements.
