THREAD DIMENSIONS PART NO. E A S1 8B-02 G1/8"x28 5.5 14 8B-04 G1/4"X19 6.5 19 8B-06 G3/8"X19 7 22 8B-08 G1/2"X14 9 27 8B-10 G5/8"×14 9 30 8B-12 G3/4"X14 10.5 32 8B-16 G1"X11 10.5 41 8B-20 G1.1/4"X11 10.5 50 8B-24 G1.1/2"X11 10.5 55 8B-32 G2"X11 10.5 70
PEHEL/BSP LOCK NUT ADAPTER
PEHEL Hydraulic Model: P8B
QTY:
BSP LOCK NUT
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: BSPP THREAD
Thread Type:BSPP
About the item:
1. Standard BSP parallel thread design (G1/8" to G2") matches 60° cone hydraulic fittings, perfectly locking bulkhead pipe connections for European standard hydraulic fluid systems.
2. Full size coverage from P8B-02 to P8B-32 with standardized A, E, S1 dimensions, meets precise interchange demands for hydraulic assembly and pipeline retrofit.
3. Carbon steel raw material with zinc electroplated finish delivers strong vibration resistance and anti-corrosion performance, stable under continuous high-pressure hydraulic operation.
4.Hexagonal outer structure enables easy wrench tightening, avoids thread slipping and loosening during equipment running, lowers pipeline leakage risk for machinery, marine and industrial hydraulics.
5. Supports bulk wholesale and custom size customization for hydraulic fitting distributors.
