PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A C H S2 22241-04-04 G1/4"X19 6 04 37.5 7.5 19 19 22241-06-06 G3/8"X19 10 06 46 9.5 21 22 22241-08-08 G1/2"X14 12 08 58.5 11.3 24 27 22241-12-12 G3/4"X14 20 12 72.5 13 30 32 22241-16-16 G1"X11 25 16 87.7 14 31.5 41 22241-20-20 G1.1/4"X11 32 20 100.5 15.5 36 50 NOTE:1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 22242-XX-XX。
Pehel/22241/In Stock 45deg Elbow Female BSP Flat Seal Swivel Hose Fitting
PEHEL Hydraulic Model: P22241
QTY:
45 Degree Elbow Female BSP Flat Seal Hydraulic Hose Crimp Fittings ISO9001:2008
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Elbow
Thread Type: Bsp flat
About the item:
1.Full through-bore design maintains consistent internal flow diameter, avoiding flow restriction that causes system heat rise and efficiency loss.
2.Chamfered tube entry guides tubing for error-free assembly, reducing installation misalignment that leads to premature seal wear.
3.Durable & Corrosion-Resistant: Made of carbon steel/stainless steel with surface treatments, extending service life.
