THREAD DIMENSIONS PART NO. E F A L S1 5TN-02SP R1/8"X28 Z1/8"X27 11 25 17 5TN-04-02SP R1/4"×19 Z1/8"X27 14.5 21.5 17 5TN-04SP R1/4"X19 Z1/4"X18 14.5 34.5 19 5TN-06-04SP R3/8"X19 Z1/4"X18 15 23 19 5TN-06SP R3/8"X19 Z3/8"X18 15 36.5 24 5TN-08-06SP R1/2"X14 Z3/8"X18 20 28.5 24 5TN-08SP R1/2"X14 Z1/2"X14 20 47 30 5TN-12-08SP R3/4"X14 Z1/2"X14 20 30.5 32 5TN-12SP R3/4"X14 Z3/4"X14 20 49 36 5TN-16-12SP R1"X11 Z3/4"X14 25.5 36.5 36 5TN-16SP R1"X11 Z1"X11.5 25.5 60 41
BSPT MALE / NPT FEMALE
PEHEL Hydraulic Model: P5TN-SP
QTY:
BSPT MALE / NPT FEMALE
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: ADAPTER
Thread Type 1: BSPT MALE
Thread Type 2: NPT FEMALE
ABOUT THE ITEM:
1. P5TN‑SP hydraulic adapter features BSPT male tapered thread and NPT female tapered thread for cross‑standard thread conversion.
2. Tapered thread‑on‑thread engagement provides reliable leak‑proof sealing for general hydraulic pipeline connections.
3. Complete size range covers R1/8"‑R1" BSPT and matching NPT thread specifications for various conversion scenarios.
4. Precisely CNC‑machined carbon‑steel body with zinc‑plated finish, offering good interchangeability and corrosion resistance.
5. Designed for transition between European BSPT and American NPT threads, widely used in industrial hydraulic systems.
