PART NO THREAD E HOSE BORE DIMENSIONS DN DASH A C S1 Per hundred weight Weight per case 13011-02-04PO R1/8''X28 6 4 17.7 10 12 300 13011-04-04PO R1/4''X19 6 4 20.5 14.5 14 2.6 300 13011-04-06PO R1/4''X19 10 6 22 14.5 17 3 250 13011-06-06PO R3/8''X19 10 6 23.5 15 19 4.2 200 13011-08-08PO R1/2''X14 12 8 30.5 20 22 7.7 150 13011-12-12PO R3/4''X14 20 12 29.4 20 27 11.8 100
PEHEL/BSPT Male Push in Hose Fitting
PEHEL Hydraulic Model: P13011-SP(PO)
QTY:
BSPT Hydraulic Hose Fitting 13011 BSPT Male Hose Fittings BSPT Rubber Hose Fittings
BSPT Male Push in Hose Fitting
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: Hose Fitting
Thread Type: BSPT MALE
About this item:
1. BSPT Male Socketless Hose Fitting — push-on hose fitting with BSPT taper male thread, model P13011-SP(PO).
2. Barbed socketless end allows quick push-on hose assembly without clamps or special tools.
3. BSPT male taper thread (R) provides a strong, leak-tight metal-to-metal seal.
4. Available from R1/8" to R3/4", covering hose bore DN6 to DN20 (dash 4-12).
5. Ideal for low- to medium-pressure hydraulic, pneumatic and lubrication systems.
