THREAD COPPER WASHER DIMENSIONS PART NO. E F F A B L S1 5B-04G G1/4"X19 G1/4"X19 DP-B04G 12 11 26 19 5B-06-04G G3/8"Xl9 G1/4"X19 DP-B04G 13.5 11 28.5 22 5B-06-08G G3/8"Xl9 G1/2"X14 DP-B08G 13.5 17 35.5 27 5B-08G G1/2"X14 G1/2"X14 DP-B08G 16 17 37 27
PEHEL/BSP MALE DOUBLE USE FOR 60° SEAT OR BONDED SEAL
PEHEL Hydraulic Model: P5B-G
QTY:
BSP MALE DOUBLE USE FOR 60° SEAT OR BONDED SEAL
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: Adapter
Thread Type: BSPP
About the item:
1. P5B‑G is pressure‑gauge adapter with BSP male double‑use end and BSP female port for gauge installation.
2. Dual‑function 60° cone seat or bonded‑seal connection enables flexible leak‑proof assembly with optional copper washer.
3. Multiple equal‑size and reducing BSP thread sizes cover G1/4"‑G1/2" for various pressure‑gauge port matching.
4. Precisely CNC‑machined carbon‑steel body with zinc‑plated finish, offering good interchangeability and corrosion resistance.
5. Compact dedicated gauge connector widely applied for pressure measuring circuits on industrial and mobile hydraulic equipment.
