NPT,SAE,PT thread for all parts is availableParameter Subplate Type 1 Subplate Type 2 Model PHS 5 C 34 P
PHS 5 C 34 PL Subplate / Type PHSC34P PHSC34PL (also seen as TYPPHC34PL) Port Configuration A-B-P-T on rear, 3/4" G A-B on side, P-T on rear, 3/4" G Weight 4.0 kg 3.7 kg Ordering Code PHS 5 C 34 P PHS 5 C 34 PL Hydraulic Symbol Shown in diagram Shown in diagram Standard CETOP 5 CETOP 5 Revision REV.01 REV.01
Pehel/PHS5C34PL/ISO Certificate Factory Made High Quality Hydraulic Subplate With All Type Port Thread
PEHEL Hydraulic Model: PHS5C34PL
QTY:
- 1. Subplate, A-B-P-T on rear=3/4”GWeight=4kg
2. Subplate, A-B on side, P-T on rear=3/4”G, Weight=3.7kg
3. up to 8 stations
4. Superior in quality and competitive in price Material: Carbon steel/Aluminum
Brand: Pehel, OEM
Color: Can be chosen
Connector Type: subplate
Thread Type: threads can be chosen
About the item:
1.Lightweight & High-Strength Hybrid: Aluminum-Carbon Steel Manifold
2.Corrosion-Resistant & Durable Hydraulic Manifold Block
3.Precision-Machined Manifold for Complex Hydraulic Circuits
4.One-Stop Customization: Threads, Coatings & Port Sizes
