PEHEL | Hydraulic Valve Subplate with A-B Side Ports and P-T Rear Ports, Carbon Steel Manifold Block

PEHEL Hydraulic Model: PHS3C14

• 1.Subplate, A-B side ports 1/2”G, P-T rear ports 1/2”G, with relief valve. (RV)
     Weight= 3 kg
  2.Subplate with A-B-P-T back ports, 2 fixing screws. Weight 0.9kg
  3.up to 8 stations
  4.NPT, SAE, PT thread for all parts is available
  5.Superior in quality and competitive in price

• • Type: Hydraulic Valve Subplate / Manifold Block

  • Port Configuration: A-B-P-T

  • Port Size: 1/2" G (customizable)

  • Port Positions: Side / Rear

  • Relief Valve: Optional (on selected models)

  • Stations: Up to 8

  • Thread Options: NPT, SAE, PT

  • Weight: 0.9kg / 3kg (depending on configuration)

  • Material: Carbon steel

  • Brand: PEHEL, OEM

  • Surface Treatment: Anti-rust coated




    1. 1.Hydraulic valve subplate designed for mounting directional control valves, featuring A-B-P-T port configurations with 1/2" G threads.

    2. 2.Available in two configurations: A-B side ports with P-T rear ports (with relief valve option, weight 3kg), or A-B-P-T all rear ports (with fixing screws, weight 0.9kg).

    3. 3.Supports multi-station configurations up to 8 stations for complex hydraulic systems requiring multiple valve mounting.

    4. 4.Thread options available in NPT, SAE, and PT to suit different system requirements.

    5. 5.Manufactured from high-strength carbon steel with anti-rust surface treatment for reliable performance and long service life.

    6. 6.Superior quality workmanship with competitive pricing for cost-effective hydraulic solutions.
