PEHEL/PHS5A12L
PEHEL Hydraulic Model: PHS5A12L
QTY:
- 1. Subplate with A-B-P-T =1/2”G, on side. Weight=3.5kg
2. Subplate with A-B-P-T =3/4”G, on side. Weight=3.7kg
3. High performance and cost effective.
4. NPT, SAE, PT thread for all parts is available About the item:
1. Strictly compliant with CETOP 5 (NG10) standard mounting dimensions, specially designed for single-station directional control valves; all A/B/P/T working ports are arranged on the side for convenient pipeline layout and space-saving installation.
2. Two standard port thread options available: 1/2”G (model PHS5A12L, weight 3.5kg) and 3/4”G (PH5C34L, weight 3.7kg), covering medium and large flow hydraulic circuit requirements for flexible selection.
3. Multiple thread standards customizable for all connection ports, including PT (BSPP), NPT and SAE threads, perfectly matching hydraulic fittings from different regional specifications worldwide.
4. Made of solid carbon steel block with precision CNC flow channel machining, featuring smooth internal oil passages to reduce flow resistance, stable pressure bearing capacity and outstanding anti-leak performance under continuous working pressure.
5. Cost-effective high-performance manifold solution, widely used for machine tools, packaging machinery, small engineering equipment and general industrial single-valve hydraulic control systems with long service life and easy maintenance.
