PART NO. STECKO SIZE DIMENSIONS LEFT RIGHT A B J K M N S1 2Y9-04 1/4" 1/4" 40.5 38 14.9 9.9 15.16 10.03 16 2Y9-06-04 3/8" 1/4" 44 42 19.9 13.9 15.16 10.03 22 2Y9-06 3/8" 3/8" 44 42.5 19.9 13.9 20.17 14.02 22 2Y9-06-08 3/8" 1/2" 46.5 46 19.9 13.9 24.16 18.03 27 2Y9-08 1/2" 1/2" 46.5 46 23.9 17.9 24.16 18.03 27 2Y9-12 3/4" 3/4" 52 51.5 28.9 23.9 29.16 24.03 36 2Y9-16-12 1" 3/4" 60 53 38.8 30.9 39.12 31.01 41 2Y9-16 1" 1" 64 63.5 38.8 30.9 39.12 31.01 48 2Y9-20 1.1/4" 1.1/4" 64 63.5 45.9 37.9 46.15 38.02 48
PEHEL | 90° Stecko Male to Stecko Female Hydraulic Fitting, Quick Connect Elbow with U‑Pin Locking System
PEHEL Hydraulic Model: 2Y9
QTY:
Type: 90° Stecko Male / Stecko Female Elbow
Connection: Staple Lock (U‑pin)
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc‑plated
1.90° Stecko male to Stecko female hydraulic elbow, designed for quick assembly and disassembly in hydraulic systems.
2.Features a staple lock (U‑pin) locking mechanism with a square cross‑slot connection structure, allowing tool‑free installation.
3.Male spigot end equipped with annular O‑ring and backup ring for sealing against the female coupling bore.
4.90° elbow configuration enables directional change of fluid flow in confined spaces.
5.Manufactured from high‑strength carbon steel with anti‑rust surface treatment for durability.
