PART NO. FLANGE SIZE HOSE BORE DIMENSIONS DN DASH A C D H L 87692-08-08 1/2" 12 08 41 31.8 23.9 48 7.9 87692-12-10 3/4" 16 10 56.5 41.3 31.7 56.5 8.9 87692-12-12 3/4" 20 12 66.3 41.3 31.7 66 8.9 87692-16-12 1" 20 12 65.8 47.6 38 69 9.6 87692-16-16 1" 25 16 78 47.6 38 74.5 9.6 87692-16-20 1" 32 20 91 47.6 38 85.5 9.6 87692-20-16 1.1/4" 25 16 78 54 43.6 78.5 10.4 87692-20-20 1.1/4" 32 20 91.5 54 43.6 89.5 10.4 87692-24-20 1.1/2" 32 20 91.5 63.5 50.8 94.5 12.7 87692-24-24 1.1/2" 40 24 110 63.5 50.8 108 12.7 87692-32-24 2" 40 24 110 79.4 66.5 116 12.7 87692-32-32 2" 50 32 132 79.4 66.5 136 12.7 NOTE:1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 87691-XX-XX。
PEHEL | 90° SAE Flange 6000 PSI Fitting for 4 Wire Hose, Carbon Steel Hydraulic Elbow
PEHEL Hydraulic Model: 87692
QTY:
Type: 90° SAE Flange Fitting
Pressure Rating: 6000 PSI
Hose Compatibility: 4‑wire spiral hose
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc‑plated
1.90° hydraulic fitting with SAE flange connection, rated for 6000 PSI and designed for use with 4‑wire spiral hydraulic hoses.
2.Flange end provides a secure, leak‑free interface when mated with corresponding flange components.
3.90° elbow configuration allows directional changes in hydraulic systems, saving installation space.
4.Manufactured from high‑strength carbon steel with anti‑rust surface treatment for long service life.
5.Precision machined flange face and threads ensure reliable sealing and consistent assembly.
