PEHEL Hydraulic Model: 3Y4
QTY:
| PART NO. | STECKO SIZE | DIMENSIONS | |||||||
| LEFT | RIGHT | A | B | M1 | N1 | M2 | N2 | S1 | |
| 3Y4-04 | 1/4" | 1/4" | 32.8 | 32.8 | 15.16 | 10.03 | 15.16 | 10.03 | 16 |
| 3Y4-06 | 3/8" | 3/8" | 35.3 | 35.3 | 20.17 | 14.02 | 20.17 | 14.02 | 22 |
| 3Y4-08 | 1/2" | 1/2" | 37 | 37 | 24.16 | 18.03 | 24.16 | 18.03 | 27 |
| 3Y4-12 | 3/4" | 3/4" | 40 | 40 | 29.16 | 24.03 | 29.16 | 24.03 | 36 |
| 3Y4-16 | 1" | 1" | 49.5 | 49.5 | 39.12 | 31.01 | 39.12 | 31.01 | 48 |
| 3Y4-20 | 1.1/4" | 1.1/4" | 49.5 | 49.5 | 46.15 | 38.02 | 46.15 | 38.02 | 48 |
Our high levels product quality,quick response 24/7 service will satisfy all of our clients.
PEHEL hydraulics is a manufacturer of hose fittings, hydraulic adapters, hose assembly, manifold block, hydraulic machine, flange fittings.
Our hydraulic products have a wide range applications, they include petrochemical, engineering machinery, injection molding machinery, mining equipment, agricultural machinery, ships, cars, machine manufacturing and custom hydraulic systems etc...
