45º SAE O-ring Boss/stecko Female

45º SAE O-ring Boss/stecko Female

PEHEL Hydraulic Model: 2OY4-OG

QTY:

  • 45º SAE O-ring Boss/stecko Female Specification
  • You May Also Like
  • PART NO. THREADE STECKO SIZE O-RINGE END DIMENSIONS
    A B M N S1 S2
    2OY4-04OG 7/16"X20 1/4" 8.92X1.83 26.5 32.8 15.16 10.03 16 17
    2OY4-06-04OG 9/16"X18 1/4" 11.89X1.98 28 32.8 15.16 10.03 16 19
    2OY4-06OG 9/16"X18 3/8" 11.89X1.98 29.8 35.3 20.17 14.02 22 19
    2OY4-06-08OG 9/16"X18 1/2" 11.89X1.98 30.5 37 24.16 18.03 27 19
    2OY4-08-06OG 3/4"X16 3/8" 16.36X2.21 33 35.3 20.17 14.02 22 24
    2OY4-08OG 3/4"X16 1/2" 16.36X2.21 34 37 24.16 18.03 27 24
    2OY4-10-08OG 7/8"X14 1/2" 19.18X2.46 39.5 37 24.16 18.03 27 27
    2OY4-12OG 1.1/16"X12 3/4" 23.47X2.95 48 40 29.16 24.03 36 32
    2OY4-16OG 1.5/16"X12 1" 29.74X2.95 50 49.5 39.12 31.01 48 41
    2OY4-20OG 1.5/8"X12 1.1/4" 29.74X2.95 50 49.5 46.15 38.02 48 50
