PART NO. THREAD O-RING DIMENSIONS E F G E F A B C S1 S2 CF-04 9/16"X18 9/16"X18 9/16"X18 O011 O011 23 23 7.5 14 19 CF-06 11/16"X16 11/16"X16 11/16"X16 O012 O012 27.5 27.5 9.5 19 22 CF-08 13/16"X16 13/16"X16 13/16"X16 O014 O014 31 31 11.5 22 27 CF-10 1"X14 1"X14 1"X14 O016 O016 36.5 36.5 12.5 27 32 CF-12 1.3/16"X12 1.3/16"X12 1.3/16"X12 O018 O018 40.3 40.3 13 30 36 CF-16 1.7/16"X12 1.7/16"X12 1.7/16"X12 O021 O021 44.5 44.5 14 36 41 CF-20 1.11/16"X12 1.11/16"X12 1.11/16"X12 O025 O025 47.5 47.5 15 41 50 CF-24 2"X12 2"X12 2"X12 O029 O029 53.5 53.5 17 50 60
PEHEL/ORFS MALE O-RING / ORFS FEMALE RUN TEE
PEHEL Hydraulic Model: PCF
QTY:
ORFS MALE O-RING / ORFS FEMALE RUN TEE
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: ORFS THREAD
Thread Type 1: ORFS MALE
Thread Type 2: ORFS MALE
Thread Type 3: ORFS FEMALE
About the item:
- 1. Compliant with SAE J1453 & ISO 8434-3 global standards, this T-type run tee adopts ORFS flat face O-ring sealing structure, supporting leak-free connection under high pressure up to 6000 PSI, with excellent resistance to vibration and pressure impact.
- 2. Unique three-port layout: two ORFS male straight thread ends with built-in O-rings and one swivel ORFS female port, enabling flexible hydraulic flow split, shunt and pipeline directional adjustment for compact system layout.
- 3. Complete full-size specifications covering CF-04 to CF-24 (9/16" up to 2" ORFS thread), matched with corresponding standard O-ring models (O011–O029), all dimension parameters strictly standardized for quick matching with American standard hydraulic hoses and adapters.
- 4. Forged high-strength carbon steel body with precision CNC machining and uniform zinc plating anti-corrosion treatment; integrated hexagonal wrench flats on each port for stable, labor-saving assembly without scratching sealing faces.
- 5. Reusable and easy to maintain design, allowing repeated disassembly and reassembly by only replacing worn O-rings; widely applicable to construction machinery, agricultural equipment, lifting platforms, machine tools and other high-pressure industrial hydraulic systems.
