PART NO. THREAD E HOSE BORE DIMENSIONS DASH A C S1 S2 P26718D-04-04R5PH 7/16"X20 04 29 9 14.29 14.29 P26718D-05-05R5PH 1/2"X20 05 34 9.4 14 17 P26718D-06-06R5PH 9/16"X18 06 36.5 9.5 19 19 P26718D-08-08R5PH 3/4"X16 08 41.5 11.7 22 22.22 P26718D-10-10R5PH 7/8"X14 10 40 12.4 25.4 25.4 P26718D-12-12R5PH 1.1/16"X12 12 45.5 14.4 32 32 P26718D-16-16R5PH 1.5/16"X12 16 37.5 15 38 41 P26718D-20-20WR5PH 1.5/8"X12 20 41 16.1 41 50 P26718D-24-24WR5PH 1.7/8"X12 24 42.5 19.5 46 55
Pehel/26718D/Female Straight JIC 74 Cone Seat Reusable Fitting For R5 Hose
PEHEL Hydraulic Model: P26718D-R5WPH
QTY:
Jic Female 74 Cone Seat Reusable Hydraulic Fitting
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Straight
Thread Type: JIC 74 Cone Seat
About the item:
1.Reusable & Cost-Effective – The insert can be reused multiple times, reducing replacement costs and inventory needs.
2.Tool-Free Assembly – Simple field attachment requires no special crimping equipment, enabling quick on-site repairs.
3.Leak-Proof JIC 74° Cone Seal – Precision-machined cone seat ensures reliable metal-to-metal sealing under high pressure.
4.Durable Material – Made from high-strength carbon steel with corrosion-resistant plating for extended service life.
5.Versatile Compatibility – Designed to fit R5 hoses and standard JIC female connectors, offering flexible system integration.
