SAE O-RING BOSS PLUG

Model: 4O

QTY:

  • You May Also Like

  • PART NO. THREAD O-RING DIMENSIONS
    E E A L S1
    4O-04 7/16"X20 8.92X1.83 9.1 16 14
    4O-05 1/2"X20 10.52X1.83 9.1 16 17
    4O-06 9/16"X18 11.89X1.98 9.9 17.5 17
    4O-08 3/4"X16 16.36X2.21 11.1 19.5 22
    4O-10 7/8"X14 19.18X2.46 12.7 23 27
    4O-12 1.1/16"X12 23.47X2.95 15.1 26.5 32
    4O-14 1.3/16"X12 26.62X2.95 15.1 27 36
    4O-16 1.5/16"X12 29.74X2.95 15.1 27.5 38
    4O-20 1.5/8"X12 37.46X3.00 15.1 30 50
    4O-24 1.7/8"X12 43.69X3.00 15.1 30 55
    4O-32 2.1/2"X12 59.36X3.00 15.1 32 70
