PART NO.
THREAD E
HOSE BORE
TUBE O.D.
O RING
DIMENSIONS
DN
DASH
A
C
H
S2
20593-36-12T
M36X2
20
12
25
O20.3X2.4
75.5
3
68
46
20593-36-16W
M36X2
25
16
25
O20.3X2.4
88.8
2.4
79.5
46
20593-42-16W
M42X2
25
16
30
O25.3X2.4
88.8
4
85.5
50
20593-42-20W
M42X2
32
20
30
O25.3X2.4
105.5
4
95
50
20593-52-20T
M52X2
32
20
38
O33.3X2.4
106.5
6.5
86.5
60
20593-52-24W
M52X2
40
24
38
O33.3X2.4
124.3
3.75
104.5
60
90 Degree Metric Female 24° Cone Seat H.T Hydraulic Fitting
PEHEL Hydraulic Model: P20593-W
QTY:
20593 Metric 90° Elbow Female 24° Cone Fittings with O Ring, Heavy Duty Series
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
About the item:
1. This 90 degree metric female elbow adopts precision 24° cone seat design for tight leak-proof hydraulic sealing.2. Made of premium carbon steel and stainless steel, delivering high hardness and strong pressure resistance.3. Exquisite silver color zinc plating surface resists rust and corrosion, adapting to harsh working environments.4. Standard metric female thread and 24° cone seat ensures accurate installation and perfect pipeline matching.5. Optimized 90° elbow structure of this 24 degree cone seat fitting simplifies complex hydraulic pipeline layout.
