PARTNO. THREAD ORING DIMENSIONS E F A B L S1 1FT-04SP 9/16"X18 R1/4"X19 7.65X1.78 9.8 14.5 30 17 1FT-06SP 11/16"X16 R3/8"X19 9.25X1.78 11.2 15 31.5 19 1FT-08SP 13/16"X16 R1/2"X14 12.42X1.78 12.8 20 40 22 1FT-10-08SP 1"X14 R1/2"X14 15.6X1.78 15.5 20 45.5 27 1FT-12SP 1.3/16"X12 R3/4"X14 18.77X1.78 17 20 47 32 1FT-12-16SP 1.3/16"X12 R1"X11 18.77X1.78 17 25.5 53.5 36 1FT-16SP 1.7/16"X12 R1"X11 23.52X1.78 17.5 25.5 52.5 38 1FT-20SP 1.11/16"X12 R1.1/4"X11 29.87X1.78 17.5 26.5 57 46 1FT-24SP 2"X12 R1.1/2"X11 37.82X1.78 17.5 26.5 59 55
Pehel | ORFS Male to BSPT Male Hydraulic Adapter
PEHEL Hydraulic Model: 1FT-SP
QTY:
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
About the item:
- 1.ORFS male to BSPT male adapter delivers tight leak‑free connection for hydraulic pipeline applications.
- 2.Available in carbon steel and stainless steel materials to meet diverse working‑condition requirements.
- 3.Silver zinc‑plated surface offers great corrosion resistance for this hydraulic ORFS‑BSPT adapter.
- 4.Precision‑machined ORFS & BSPT male threads ensure smooth assembly and stable sealing performance.
- 5.Supports Pehel standard supply and OEM custom service for different hydraulic fitting project demands.
