PART NO. THREAD TUBE O.D. DIMENSIONS E F D A B S1 S2 5QN-12-02 M12X1.5 Z1/8"X27 6 16.7 31.9 14 14 5QN-14-04 M14X1.5 Z1/4"X18 8 17 38.3 19 17 5QN-16-06 M16X1.5 Z3/8"X18 10 18 41 22 19 5QN-18-06 M18X1.5 Z3/8"X18 12 18 40.9 22 22 5QN-22-08 M22X1.5 Z1/2"X14 14 19.5 48.4 30 27 5QN-27-12 M27X1.5 Z3/4"X14 18 20 50.4 36 32 5QN-36-16 M36X2 Z1"X11.5 25 25 61.6 41 41 5QN-42-20 M42X2 Z1.1/4"X11.5 32 28.5 67.4 50 50 Note: In case if you are interested to order the adapter in complete set with sleeve and nut ,it is necessory to inset suffix "RN" in after of part no., for example 5QN-18-06RN.
Pehel | P5QN | Hydraulic Metric Male 74 /NPT Female Hose Adapter
PEHEL Hydraulic Model: 5QN
QTY:
Material: Carbon steel
Brand: Pehel
Color: Silver
OEM Designed: Yes
Surface Treatment: Zinc Plated
Thread: Metric /NPT
About the item:
1. Versatile fittings – connect metric male to NPT female systems seamlessly.
2. Metric male thread – conforms to DIN/ISO standards for exact fit.
3. NPT female port – tapered thread provides self-sealing, leak-tight connections.
4. Durable steel body – corrosion-resistant for high-pressure durability.
5. Easy installation – standard threads allow quick and secure assembly.
