PART NO. THREAD O-RING DIMENSIONS E F E A B S1 S2 5ON9-04OG 7/16"X20 Z1/4"X18 8.92X1.83 31.5 22.4 16 17 5ON9-04-02OG 7/16"X20 Z1/8"X27 8.92X1.83 30 16.8 14 17 5ON9-05-02OG 1/2"X20 Z1/8"X27 10.52X1.83 30 16.8 14 17 5ON9-05-04OG 1/2"X20 Z1/4"X18 10.52X1.83 31.5 22.4 16 17 5ON9-06OG 9/16"X18 Z3/8"X18 11.89X1.98 36.5 26.5 22 19 5ON9-06-04OG 9/16"X18 Z1/4"X18 11.89X1.98 33.3 22.4 16 17 5ON9-06-08OG 9/16"X18 Z1/2"X14 11.89X1.98 40 31.2 27 19 5ON9-08OG 3/4"X16 Z1/2"X14 16.36X2.21 43 31.2 27 24 5ON9-08-06OG 3/4"X16 Z3/8"X18 16.36X2.21 40 26.5 22 24 5ON9-08-12OG 3/4"X16 Z3/4"X14 16.36X2.21 47 34.5 33 24 5ON9-10-06OG 7/8"X14 Z3/8"X18 19.18X2.46 44 26.5 22 27 5ON9-10-08OG 7/8"X14 Z1/2"X14 19.18X2.46 48 31.2 27 27 5ON9-12OG 1.1/16"X12 Z3/4"X14 23.47X2.95 55 34.5 33 32 5ON9-12-08OG 1.1/16"X12 Z1/2"X14 23.47X2.95 51 31.2 27 32 5ON9-12-16OG 1.1/16"X12 Z1"X11.5 23.47X2.95 59.5 41.1 41 32 5ON9-14-12OG 1.3/16"X12 Z3/4"X14 26.62X2.95 56 34.5 33 36 5ON9-16OG 1.5/16"X12 Z1"X11.5 26.62X2.95 59.5 41.1 41 41 5ON9-16-12OG 1.5/16"X12 Z3/4"X14 29.74X2.95 54.5 34.5 33 41 5ON9-20OG 1.5/8"X12 Z1.1/4"X11.5 37.46X3.00 63 43.2 48 50 5ON9-24OG 1.7/8"X12 Z1.1/2"X11.5 43.69X3.00 76 52.8 63 55
Pehel | 90 Degree SAE O-Ring Boss NPT Female Hydraulic Elbow Adapter
PEHEL Hydraulic Model: 5ON9-OG
QTY:
- Material: Carbon steel, stainless steel
- Brand: Pehel, OEM
- Color: Silver color zinc plating
- Connector Type: 90 Degree Transition Elbow
- Thread Type: SAE O-Ring Boss Straight Thread / NPT Female Taper Thread
- About the item:
- 1.This 90 degree hydraulic elbow combines SAE O-Ring Boss and NPT female thread for seamless cross-standard pipeline conversion.
- 2.SAE ORB NPT female elbow fitting made of carbon steel & stainless steel owns stable high pressure bearing capacity.
- 3.Fine silver zinc plating on hydraulic pipe fitting provides reliable rust and corrosion resistance for long industrial use.
- 4.Accurately machined dual thread of transition connector ensures tight fit and prevents oil leakage under mechanical vibration.
- 5.We offer standard Pehel hydraulic transition fitting and flexible OEM service for custom marking, packaging and sizes.
