PART NO. THREAD O-RING DIMENSIONS E F E F A B S1 S2 6F9-04 9/16"X18 9/16"X18 O011 O011 23 47 14 22 6F9-06 11/16"X16 11/16"X16 O012 O012 27.5 52 19 27 6F9-08 13/16"X16 13/16"X16 O014 O014 31 55.5 22 30 6F9-10 1"X14 1"X14 OO16 O016 36.5 63 27 36 6F9-12 1.3/16"X12 1.3/16"X12 O018 O018 41 67.2 30 38 6F9-16 1.7/16"X12 1.7/16"X12 O021 O021 44.5 71.2 36 46 6F9-20 1.11/16"X12 1.11/16"X12 O025 O025 47.5 75.5 41 50 6F9-24 2"X12 2"X12 O029 O029 53.5 79.5 50 60
PEHEL | ORFS Bulkhead Elbow Fitting SAE J1453 Male O-Ring 90 Degree 6F9-LN
PEHEL Hydraulic Model: P6F9/P6F9-LN
QTY:
Material:Carbon steel
Brand:Pehel, OEM
Color: Silver
Connector Type: Elbow Bulkhead Adapter
Thread Type: ORFS
Surface Treatment: Cr3+ White Zinc Plated
About the item:
· 1.Forged Construction: Ensures durability and strength for heavy-duty applications.
· 2.High Pressure Rating: Designed to withstand high-pressure hydraulic systems.
· 3. Zinc Plated Finish: Provides rust resistance and enhances longevity.
· 4. Strict tolerance crimp stem enables stable hose crimping, avoids hose pull-off & oil seepage.
· 5. Customizable Options: Available in various sizes and configurations for tailored solutions.
