PART NO. THREAD DIMENSIONS E F A B L S1 1NL-02-10 Z1/8"X27 M10X1 10.5 8 25.5 17 1NL-02-12 Z1/8"X27 M12X1.5 10.5 12 30 17 1NL-04-14 Z1/4"X18 M14X1.5 15 12 34.5 19 1NL-04-16 Z1/4"X18 M16X1.5 15 12 36.5 22 1NL-06-18 Z3/8"X18 M18X1.5 16 12 37.5 24 1NL-08-22 Z1/2"X14 M22X1.5 19.5 14 45 27 1NL-12-27 Z3/4"X14 M27X2 19.5 16 48.5 34 1NL-16-33 Z1"X11.5 M33X2 25.5 18 58.5 41 1NL-20-42 Z1.1/4"X11.5 M42X2 26.5 20 63.5 50
NPT MALE/METRIC BONDED SEAL
PEHEL Hydraulic Model: 1NL
QTY:
