NPT FEMALE/NPSM FEMALE60 CONE

Model: 7NU-S

QTY:

  • You May Also Like

  • PART NO THREAD DIMENSIONS
    E F B L S1 S2
    7NU-02S Z1/8''X27 1/8''X27 3.5 24 17 15
    7NU-04-02S Z1/4''X18 1/8''X27 3.5 29 19 15
    7NU-04S Z1/4''X18 1/4''X27 4.6 31.5 19 19
    7NU-04-06S Z1/4''X18 3/8''X18 6 33 19 22
    7NU-06S Z3/8''X18 3/8''X18 6 34 22 22
    7NU-06-08S Z3/8''X18 1/2''X14 7.5 34 22 27
    7NU-08-06S Z1/2''X14 3/8''X18 6 39 30 22
    7NU-08S Z1/2''X14 1/2''X14 7.5 41 30 27
    7NU-12S Z3/4''X14 3/4''X14 8.9 44 36 32
    7NU-16S Z1''X11.5 1''X11.5 10.5 51.5 41 41
    7NU-20S Z1.1/4''X11.5 Z1.1/4''X11.5 11.2 55 50 50
    7NU-24S Z1.1/2''X11.5 Z1.1/2''X11.5 11.2 55.5 60 55
    7NU-32S Z2''X11.5 2''X11.5 11.5 57 70 70
