NPT,SAE,PT thread for all parts is available
PEHEL/PHM203..YK
PEHEL Hydraulic Model: PHM203..YK
QTY:
- 1. Monoblock with ports P-T=1/2”G and A-B=3/8”G on the side.
2. Pre-arrange for “VEI” 2/2 by pass valve normally open (N.A.) or normally close.(N.C.)
3. up to 8 stations
4. Superior in quality and competitive in price About the item:
1. Standard side port layout with carbon steel monoblock structure: P&T ports adopt 1/2”G thread, while A&B working ports are 3/8”G, complying with CETOP 3 installation standard for directional valves.
2. Pre-machined cavity reserved for VEI 2/2 bypass valve, supporting two optional configurations: normally open (N.A.) or normally closed (N.C.) to meet diverse hydraulic circuit bypass control demands.
3. Flexible station customization, available in 1–8 independent valve stations, with compact parallel oil circuit design to simplify hydraulic system piping layout.
4. Rich thread compatibility: NPT, SAE and PT thread standards are all configurable for all connection ports, convenient for matching different regional hydraulic fittings and pipelines.
5. Adopts precision machining and scientific flow channel design, featuring stable pressure resistance, superior durability and highly competitive cost performance for industrial hydraulic machinery applications.
